Tube Cutting Saw Machine

​

Automatic Dual Tube Cutting Saw Machine

Step into the realm of efficiency with our specialized webpage on automatic tube saws. Experience cutting-edge technology that streamlines tube cutting tasks, delivering rapid and precise results every time. Perfect for industries seeking consistent and high-quality outcomes, our handpicked collection of automatic tube saws promises unparalleled performance. Browse through detailed product specifications, real-world user reviews, and expert insights to optimize your tube cutting operations. When speed meets precision in the world of tube cutting, automatic saws lead the way. Discover the future of hassle-free and flawless tube cutting right here.

Enquire Now Download Spec Sheet




  • Automatic loading magazine for tubing and solid bars up to 6.5 meters in length
  • Automatic single or double tube loading, feeding, and sawing machines ( Cold Saw )
  • Automatic first and crop cuts separation Circular Sawing Machines
  • Automatic speed variation during cutting

– Lowest RPM during blade entry

– High RPM after cutting through the tube’s wall

– Lower RPM at re-entry into tube’s lower wall

  • Suitable for non-stop, 24 hours operation
  • One or two tube’s cutting
  • Dual blade cutting system – HSS and / or TCT (tungsten carbide tipped)
  • Touch screen system for operation, file editing and storage
  • Self-diagnostics and error display on-screen for troubleshooting
  • +/- 0.1 mm length tolerance (single tube cutting)
  • Electric servo-controlled feeding
  • Electric servo-controlled cutting (Circular Saw)
  • Floating feeding carriage
  • Patented backlash eliminating system
  • Triple slide structure for vertical moving saw head for smooth cutting through the entire
  • 180 degrees blade holding guides to eliminate vibration
  • High-efficiency gearbox with brake system
  • High-pressure blade cooling system
  • Sawing head temperature control
Model Number
SB-12x3A-2S
SB-19x3A-2S
SB-30x4A-2S
SB-39x3A-1S
SB-39x4A-2S
Model Weight (lbs.)2425308637485842 (1S)
6283 (2S)
Model Dimensions (ft.)7 x 3 x 410 x 3 x 411 x 3 x 414 x 5 x 4 (1S)
15 x 4 x 4 (2S)
Mild SteelØ10.0 x 1.2tØ19.05 x 1.0tØ30.0 x 1.5tØ38.1 x 3.17t
Stainless SteelØ10.0 x 0.9tØ16 x 1.0tØ25.4 x 1.2tØ38.1 x 2.2t
Max Tube Length w/ Mandrel1650230026703000 (1S)
3850 (2S)
Max Draw Bend60 mm80 mm120 mm180 mm
Max Bending Radius25 mm30 mm38 mm50 (2S) mm
Bending Accuracy+/-0.1 mm
+/-0.1 mm
+/-0.1 mm
+/-0.1 mm
Rotation Accuracy+/-0.1°
+/-0.1°
+/-0.1°
+/-0.1°
Feeding Accuracy+/-0.1 mm
+/-0.1 mm
+/-0.1 mm
+/-0.1 mm
Model Number
SA-80CNC-ST
Model Weight3000 kg
Model Dimensions7210 mm x 2235 mm x 1950 mm
Cutting CapacitySingle Round Tube Ø15 mm ~ Ø80 mm
Dual Round Tubes Ø15 mm ~ Ø40 mm
Feeding CapacityFeeding Length 6 mm ~ 1000 mm
First Crop 12mm ~ 60 mm
Last Crop 75 mm + α
BladeØ275 ~ Ø360 mm
Water Soluble Cooling Lubricating Oil
Auto Circulation Pump 1/2HP(*)
Cutting HeadSpindle Motor 5HP, 4 Poles
RPM 25-180
Feeding WayServo Drive
Spindle Motor RPM20-180
Chip DisposalAutomatic Chip Conveyor
Hydraulic SystemMotor: 2HP, 4 Poles
Pressure 50 kg/cm2
Feeding SystemServo Motor
Positive Feeding or Gripper Feeding
Loading MagazineStandard Width: 800 mm
Standard Capacity: 1700 kg
Material Length: 3000mm ~ 6200 mm
